Qvis HDCVI-MB1 User Manual

1 megapixel hdcvi bullet & dome cameras

Advertisement

Quick Links

HDCVI-MB1
HDCVI-EYE1
1 Megapixel HDCVI Bullet & Dome Cameras
User's Manual
V1.0 06 / 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDCVI-MB1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Qvis HDCVI-MB1

  • Page 1 HDCVI-MB1 HDCVI-EYE1 1 Megapixel HDCVI Bullet & Dome Cameras User’s Manual V1.0 06 / 2014...
  • Page 3 Welcome Thank you for purchasing either the HDCVI Bullet or Eyeball Dome cameras. This user’s manual is designed to be a reference tool for the installation and operation of your camera setup. Here you can find information about the corresponding HDCVI camera’s features and functions, as well as a detailed installation method.
  • Page 4: Important Safeguards And Warnings

    Important Safeguards and Warnings 1.Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.
  • Page 6: Table Of Contents

    Table of Contents 1 General Introduction......................1 Overview........................1 Features......................1 Functions ......................1 Specifications....................2 Framework and Dimensions...................4 HDCVI-MB1 ....................3 HDCVI-EYE1………..................5 Installation .......................6 HDCVI-MB1.....................6 HDCVI-EYE1……....................7...
  • Page 7: General Introduction

    Smart IR technology The sensor controls the IR light and can switch it on/off via hardware and software working in combination, which can automatically provide IR light compensation according to the environment illumination conditions. © Copyright Qvis ®. All documentation rights reserved.
  • Page 8 System can automatically set the shutter speed and iris value according to the snapshot video exposure conditions. Auto electronic shutter The system can automatically adjust the electronic shutter when the environment’s light changes. © Copyright Qvis ®. All documentation rights reserved.
  • Page 9: Specifications

    -30 ~+60℃℃. Humidity is less than 95%(no condensation) Humidity Power DC 12V±10% Power Consumption 3.5W MAX 2.5W MAX (Input: 12V 0.29A) (Input: 12V 0.21A) φ65.0×154.7 φ113.6×85.4 Dimensions (mm) Weight 380g 200g Installation Mode Wall Mount Wall mount/in-ceiling mount © Copyright Qvis ®. All documentation rights reserved.
  • Page 10: Framework And Dimensions

    • BNC port: This is to output the HDCVI video signal. Video output port • You can connect to the devices such as the DVR or the NVS conforming to the HDCVI specifications. © Copyright Qvis ®. All documentation rights reserved.
  • Page 11: Hdcvi-Eye1

    • BNC port: This is to output the HDCVI video signal. Video output port • You can connect to the devices such as the DVR or the NVS conforming to the HDCVI specifications. © Copyright Qvis ®. All documentation rights reserved.
  • Page 12: Installation

    Step 3: Adjust the camera to point in the direction of the desired monitor area via the three directions indicated in Figure 3-2 after you fixed the camera into place. © Copyright Qvis ®. All documentation rights reserved.
  • Page 13: Hdcvi-Eye1

    Put the three self-tapping screws in the three plastic expansion bolts firmly. Now the dome camera is secure in the installation surface. See Figure 3-3 © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 Fix the screw again. Important: Do not remove the screw. Only loosen it a little. Please secure after you completed the setup. Figure 3-4 © Copyright Qvis ®. All documentation rights reserved.
  • Page 15 Then you can draw out the cable from the cable channel of the pedestal. Finally you can install the decoration ring to complete the installation. See Figure 3-5. Figure 3-5 © Copyright Qvis ®. All documentation rights reserved.
  • Page 16 For more information about our other Analogue Cameras and other available HDCVI equipment, DVRs, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
