  • Page 1 APOIP-EYE1.3 APOIP-EYE2 1.3 & 2 MEGA PIXEL EYEBALL DOME IP CAMERAS User’s Manual...
  • Page 3 Welcome Thank you for purchasing the 1.3 or 2 Mega Pixel Eyeball Dome IP Cameras. This user’s manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about the corresponding IP camera’s features and functions, as well as a detailed installation method.
  • Page 4 Important Safeguards and Warnings 1.Electrical safety  All installation and operation here should conform to your local electrical safety codes.  The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and must make sure that the limited power source is rated 12V DC or 24V AC. Please note: Do not connect two power supplying sources to the device at the same time;...
  • Page 5  Please make sure the CCD (CMOS) component is away from the radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component damage.  It is recommended that the grounding studs of the product should be grounded, so to further enhance the reliability of the camera.
  • Page 6: Table Of Contents

    Table of Contents General Introduction ...................... 1 Overview ......................1 Features ......................1 Specifications ....................2 1.3.1 Performance ....................2 Factory Default Setup ..................4 Structure ........................9 Components ...................... 9 Framework and Dimension ................10 Device Installation ....................... 11 Installation Steps .....................
  • Page 7: General Introduction

     External power adapter DC12V.  Supports s PoE supply Warning! Power Do not connect these two power supplying sources to the device at the same time; it may result in device damage! © Copyright Qvis ®. All documentation rights reserved.
  • Page 8: Specifications

    PAL: It ranges from 1/3 to 1/10000 NTSC: It ranges from 1/4 to 1/10000 Video Compression H.264/JPEG/MJPEG Standard PAL: PAL: Video Frame Main stream(1920*1080@25fps), Main stream: (1280x960@15fps) Rate extra stream,(704*576@25fps) Extra stream: (704×576) or (352×288) @ 25fps © Copyright Qvis ®. All documentation rights reserved.
  • Page 9 Power 4.5W MAX Consumption Working C ~+60 Temperature Working 10%~90% Humidify Φ113×86 Dimensions(mm) Weight 280g(Excluding box) 400g (Excluding box) Installation Fixed on the wall, ceiling, etc. © Copyright Qvis ®. All documentation rights reserved.
  • Page 10: Factory Default Setup

    I Frame interval Watermark Enable Watermark DigitalCCTV character Enable Enable Bit stream General type Encode H.264B mode Resolution CIF(352*288) Stream PAL: 25 Frame Rate(FPS) NTSC:30 Bit Rate Type Recommend 192-1024Kb/S ed Bit © Copyright Qvis ®. All documentation rights reserved.
  • Page 11 TCP/IP Default 192.168.1.1 Gateway Preferred 8.8.8.8 Alternate 8.8.8.8 Enable ARP/Ping set Enable device address service Connection 37777 TCP Port 37778 UDP Port Connection HTTP Port RTSP Port Enable HTTP Disable HTTPs Port © Copyright Qvis ®. All documentation rights reserved.
  • Page 12 Email Test Disable,interval=60 seconds UPnP Enable UPnP Disable SNMP Port Read public Community Write private Community SNMP Trap Address Trap Port SNMP v1:Disable SNMP Version SNMP v2:Disable SNMP v3:Disable Bonjour Enable Enable © Copyright Qvis ®. All documentation rights reserved.
  • Page 13 Record Mode Auto Bit Stream Main Stream Device No Device MAC address Language English Local Host Video PAL/NTSC Standard Date Format Y-M-D Time Format Date and time Time Zone GMT+08:00 System Time Sync © Copyright Qvis ®. All documentation rights reserved.
  • Page 14 00:00:00 of the first Sunday of the month End Time 00:00:00 of the second Monday of the month Disable NTP Server clock.isc.org Port 10 minutes Update Period Auto Reboot Enable Auto Maintenance Auto Delete Disable Old Files © Copyright Qvis ®. All documentation rights reserved.
  • Page 15: Structure

    Component Name Component 1 Device lens Component 2 Dome body Component 3 Dome enclosure Port Name Connector Note Network connect standard Ethernet port Ethernet. To connect to DC12V power DC12V power supply. © Copyright Qvis ®. All documentation rights reserved.
  • Page 16: Framework And Dimension

    2.2 Framework and Dimension Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and Figure 2-3. Figure 2-2 Figure 2-3 © Copyright Qvis ®. All documentation rights reserved.
  • Page 17: Device Installation

    Line up the three spigots of the decoration ring to the jags from the bottom to the top and then turn clockwise until you hear a clear sound ”KA”. Now the installation is complete. Figure 3-1 © Copyright Qvis ®. All documentation rights reserved.
  • Page 18 Please earth the GND port of the device to enhance the device reliability. The GND port is near the cable exit port on the rear of the dome. The GND screw uses the M2X5 pan screw. © Copyright Qvis ®. All documentation rights reserved.
  • Page 19: Restore Factory Default Setup Introduction

    Step5: Put the dome back to the dome cover. Please refer to Step 4 in Chapter 3.1 to install the decoration ring back. Figure 3-5 © Copyright Qvis ®. All documentation rights reserved.
  • Page 20: Quick Configuration Tool

    The factory default user name is admin and password is admin. For security reasons, please modify your password after you first login. For detailed WEB operation, please refer to the Network Camera Web Operation Manual in the resource CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 21 Or you can select an IP address and then click the Login button to go to the login interface. See Figure 4-4. In Figure 4-4, you can view device IP address, user name, password and port. Please modify the corresponding information to login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 22 After you logged in, the configuration tool main interface is shown as below. See Figure 4-5. Figure 4-5 Main interface For detailed information and operation instructions of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD. © Copyright Qvis ®. All documentation rights reserved.
  • Page 23: Web Operation

    2. The login interface is shown as below. See Figure 5-2. 3. Please input your user name and password. 4. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. © Copyright Qvis ®. All documentation rights reserved.
  • Page 24 If you can’t download the ActiveX file, please check whether you have installed the plug-in to disable the control download. Or you can lower the web browser’s security level. See Figure 5-3. Figure 5-3 IE security level © Copyright Qvis ®. All documentation rights reserved.
  • Page 25 After you logged in, you can see the main window. See Figure 5-4: Figure 5-4 Web monitoring window © Copyright Qvis ®. All documentation rights reserved.
  • Page 26: Faq

    Note  This user’s manual is for reference only. Slight differences may be found in user interface.  All the designs and software here are subject to change without prior written notice. © Copyright Qvis ®. All documentation rights reserved.
  • Page 27 For more information about our IP Cameras and other available cameras, NVRs & accessories, please visit our website: www.adata.co.uk Alternatively scan this QR code with your smart phone to be directed instantly to our website: © Copyright Qvis ®. All documentation rights reserved.
