Technical Specifications; Table 2-2. Wibox Technical Specifications - Lantronix Ethernet User Manual

Technical Specifications

CPU, Memory
Serial Interface
Network Interface
Power Supply
Power Input
Dimensions
Weight
Temperature
Relative Humidity
WiBox2100E User Guide

Table 2-2. WiBox Technical Specifications

Lantronix DSTni-EX 186 CPU
256 KB zero wait state SRAM
2048 KB Flash
Rate is software selectable (300 bps to 921600 bps)
Wireless 802.11b/g
10/100 RJ45 Ethernet (WBX2100E only)
External adapter included
120 VAC (1-01 models) USA
100 – 240 VAC (2-01 models) Universal with regional
connectors
9 – 30 VDC (2.5 W maximum)
DC input
Height: 2.3 cm (0.9 in)
Width: 7.3 cm (2.87 in)
Depth: 9.5 cm (3.74 in)
0.28 kg (0.62 lbs)
Operating temperature range: -40
°
158 F).
Storage temperature range: -40
Operating: 10% to 90% non-condensing, 40% to 60%
recommended
Storage: 10% to 90% non-condensing
Introduction
° ° °
C to 70 C (-40 F to
° ° °
C to 85 C (140 F to 185
18
°
F)
