Lantronix Ethernet User Manual page 35

Baud Rate
Data Bits
Parity
Stop Bits
Pack Control
Enable Packing
Idle Gap Time
Match 2 Byte Sequence
Match Bytes
Send Frame Only
Send Trailing Bytes
Flush Input Buffer (Serial to Network)
With Active Connect
With Passive Connect
WiBox2100E User Guide
The unit and attached serial device, such as a modem, must
agree on a speed or baud rate to use for the serial connection.
Valid baud rates are 300, 600, 1200, 2400, 4800, 9600
(default), 19200, 38400, 57600, 115200, 230400, 460800, or
921600. For baud rates 460 and 921 Kbps, the CPU
Performance Mode must be set to High.
Indicates the number of character bits. The default setting is 8.
Checks for the parity bit. The default setting is None.
The stop bit follows the data and parity bits in serial
communication. It indicates the end of transmission. The
default setting is 1.
Select the checkbox to enable packing on the WiBox.
Two firmware-selectable packing algorithms define how and
when packets are sent to the network.
The standard algorithm is optimized for applications in which
the unit is used in a local environment, allowing for very small
delays for single characters, while keeping the packet count
low.
The alternate packing algorithm minimizes the packet count
on the network and is especially useful in applications in a
routed Wide Area Network (WAN). Adjusting parameters in
this mode can economize the network data stream.
Disabled by default.
Select the maximum time for inactivity. The default time is 12
milliseconds.
Use to indicate the end of a series of data to be sent as one
group. The sequence must occur sequentially to indicate the
end of data collection to the WiBox. The default setting is No.
Use to indicate the end of a series of data to be sent as one
group. Set this value to 00 if specific functions are not needed.
After the detection of the byte sequence, indicates whether to
send the data frame or the entire buffer. Select Yes to send
only the data frame. The default setting is No.
Select the number of bytes to send after the end-of-sequence
characters. The default None.
Select Yes to clear the input buffer with a connection that is
initiated from the device to the network. The default setting is
No.
Select Yes to clear the input buffer with a connection initiated
from the network to the device. The default setting is No.
Web-Manager Configuration
35
