WebPort
Maximum Baud Rate
Supported
Firmware Upgradeable
IP Address
Number of COB
partitions supported
Supports DynamicIP
Subnet Mask
Gateway
Number of Ports
TCP Keepalive valid
range
Supports Configurable
Pins
Supports Email Triggers
Supports AES Data
Stream
Supports 485
Supports 920K Baud
Rate
Supports Wired Ethernet
WiBox2100E User Guide
Displays the WiBox's port for Web-Manager configuration.
Displays the WiBox's maximum baud rate.
may not currently be running at this rate.
Displays True, indicating the WiBox's firmware is upgradeable
as newer version become available.
Displays the WiBox's current IP address. To change the IP
address, click the Assign IP Address button.
Displays the number of COB partitions supported (between 19
and 59).
Indicates whether the current IP address was set using static
or DHCP.
Displays the WiBox's current subnet mask. To change the
subnet mask, click the Assign IP Address button.
Displays the WiBox's current gateway. To change the
gateway, click the Assign IP Address button.
Displays the number of ports on the WiBox.
Displays 45, the WiBox's TCP keepalive range.
False
False
Displays True if the WiBox unit supports AES encryption.
Displays True if the WiBox supports the RS-485 protocol.
Displays True if the WiBox supports baud rates up to 920K.
WBX2100E supports wired Ethernet.
Quick Start
Note: The WiBox
