Command
SC
PI x.x.x.x
AT
TT
NC
RS
QU
G0, G1, ....,Ge, Gf
S0, S1,...,Se, Sf
GM
SS
Responses to some of the commands are given in Intel Hex format.
Note: Entering any of the commands listed above generates one of the
following command response codes:
WiBox2100E User Guide
Command Name
Send Configuration
Ping
ARP Table
TCP Connection
Table
Network Connection
Reset
Quit
Get configuration
from memory page
Set configuration to
memory page
Get MAC address
Set Security record

Table 9-2. Command Response Codes

Response Meaning
0> OK; no error
1> No answer from remote device
2> Cannot reach remote device or no answer
8> Wrong parameter(s)
9> Invalid command
Function
Sets configuration of unit from hex records.
Pings unit with IP address x.x.x.x to check device
status.
Shows the unit's ARP table entries.
Shows all incoming and outgoing TCP connections.
Shows the unit's current IP address.
Resets the unit.
Exits diagnostics mode.
Gets a memory page of configuration information
from the device.
Sets a memory page of configuration information
on the device.
Shows the unit's 6-byte MAC.
Sets the Security record without the encryption key
and length parameters. The entire record must still
be written, but the encryption-specific bytes do not
need to be provided (they can be null since they
are not overwritten).
Monitor Mode
