Ad Hoc WiBox Connection

In the example above, two WiBoxes have established an Ad Hoc peer-to-peer
relationship. They communicate directly to each other's serial devices without a PC
or an AP.

WiBox with Ethernet

With this model, you can select either a wireless or an Ethernet connection.

Protocol Support

The WiBox device server uses the TCP/IP protocol stack for network
communications. Other supported protocols include:

Configuration Methods

After the physical installation of the WiBox, configuration is required. For the unit to
operate correctly on a network, it must have:
Methods for logging into the device server and assigning IP addresses (as well as
setting other configurable parameters) include:
Web-Manager: Through a web interface, configure the WiBox and its settings using
the WiBox's Web-Manager. (See
Serial & Telnet Ports: There are two approaches to accessing Setup Mode. Make a
Telnet connection to the network port (9999) or connect a terminal (or a PC running a
terminal emulation program) to the unit's serial port. (See
(Setup Mode)
WiBox2100E User Guide

Figure 2-4. Direct WiBox to WiBox Connection

ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, and SNMP for
network communications and management.
TCP, UDP, and Telnet for connections to the serial port.
TFTP for firmware and web page updates.
IP for addressing, routing, and data block handling over the network.
User Datagram Protocol (UDP) for typical datagram applications in which
devices interact with other devices without maintaining a point-to-point
connection.
A unique IP address
Appropriate settings for network communications
Configuration.)
4: Web-Manager.)
Introduction
5: Telnet or Serial Port
13
