Figure 4-6. Tcp Connection Settings - Lantronix Ethernet User Manual

Connect Mode: Passive Connection
Accept Incoming
Password Required
Password
Connect Mode: Active Connection
Active Connect
WiBox2100E User Guide

Figure 4-6. TCP Connection Settings

Select Yes to accept incoming connections.
Determines whether a password is required for an incoming
passive connection. This field is not available when a
password is set for Telnet mode. The default setting is No.
If Password Required was set to Yes, enter the password for
passive connections.
Select None (default) to disable Active Connect. Otherwise,
indicate the connection type from the drop-down list:
With Any Character: Attempts to connect when any
Web-Manager Configuration
37
