Introduction

Figure 2-7. RS-485 2-Wire Pinouts

WBX2100E Network Interface

The back panel of the WBX2100E contains a 9-30VDC power plug and an RJ45
(10/100) Ethernet port.

Figure 2-8. Network Interface

Power Plug
RJ45 Ethernet Port (WBX2100E only)
WiBox2100E User Guide 16
