5. On the main menu, click Apply Settings.

Static IP Address Configuration

To manually assign an IP address and its network configuration:
1. Click Network from the main menu.
2. Select Use the following IP configuration.
3. Enter the following (as necessary):
IP Address
Subnet Mask
Default Gateway
4. Click the OK button when finished.
5. On the main menu, click Apply Settings.

Ethernet Configuration

You must specify the speed and direction of data transmission.
To specify how data will be transmitted:
1. On the main menu, click Network.
2. Enter the following (as necessary):
Auto Negotiate
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.

Server Configuration

The unit's server values display upon selecting Server from the main menu. The
following sections describe the configurable parameters within the Server
configuration menu.
WiBox2100E User Guide
If DHCP is not used to assign IP addresses, enter it manually.
The IP address must be set to a unique value in the network.
A subnet mask defines the number of bits taken from the IP
address that are assigned for the host part.
The gateway address, or router, allows communication to
other LAN segments. The gateway address should be the IP
address of the router connected to the same LAN segment as
the WiBox. The gateway address must be within the local
network.
With this option, the Ethernet port auto-negotiates the speed
and duplex with the hardware endpoint to which it is
connected. This is the default setting.
If this option is not selected, complete the fields that become
available:
Speed: The speed of data transmission. The default setting is
100 Mbps.
Duplex: The direction of data transmission. The default
setting is Full.
Web-Manager Configuration
