3.12 MASTER/SLAVE MODE WITH DMX SIGNAL CABLE

This mode will allow you to link up the units together without a controller. Choose a unit to function as the
Master. The unit must be the first unit in line; other units will work as slave.
• Use standard DMX cables to daisy chain your units together via the DMX connector on the rear of the
units. For longer cable runs we suggest a terminator at the last fixture (see page 16).
• Use any one of the standalone modes for the master unit.
• Set the slaves to the same DMX modes.
3.13 MASTER/SLAVE MODE WITH WIRELESS SIGNAL
This mode allows you to wirelessly connect more units SMARTBAT, without a controller. The first unit,
transmitter signal, it will be set as master and the others, receivers, as slave.
Wireless communication between devices can be configured in two ways:
Manual transmit/receive mode
On Master unit:
• Press the MENU button so many times until the display shows [S-tr].
• Press the ENTER button to confirm.
• Press the UP/DOWN button and select [dtCH].
• Press the ENTER button to confirm.
• Press the UP/DOWN button, select one of the transmitting signal [dt 1 - dt 16].
• Press the ENTER button for save the setting.
On Slave unit:
• Press the MENU button so many times until the display shows [S-tr].
• Press the ENTER button to confirm.
• Press the UP/DOWN button and select [drCH].
• Press the ENTER button to confirm.
• Press the UP/DOWN button, select one of the transmitting signal [dr 1 - dr 16].
• Press the ENTER button for save the setting.
Auto transmit/receive mode
On Master unit:
• Press the MENU button so many times until the display shows [S-tr].
• Press the ENTER button to confirm.
• Press the UP/DOWN button and select [dtAS].
• Press the ENTER button to confirm.
• Press the ENTER button again to confirm [dtAU].
On Slave unit:
• Press the MENU button so many times until the display shows [S-tr].
• Press the ENTER button to confirm.
• Press the UP/DOWN button and select [drAS].
• Press the ENTER button to confirm.
• Press the ENTER button again to confirm [drAU].
On Master unit:
• Hold the AUTO button.
On Slave unit:
• Hold the AUTO button (always hold AUTO button on Master unit).
• Wait 5 seconds and release the AUTO button on Slave unit.
Note: Use any one of the standalone modes for the master unit. Set the slaves to the same DMX modes.
