Real -time Monitor tab
Basic Test Data tab
2
3
Trend Test Data tab
4
Profile create, edit, upload and Profile Test Data tab
5
Start Measuring button
6
End Measuring button
7
Start Recording button
8
Pause Recording button
9
Setting button updates the instrument setting through the PC.
10
Table area shows test data in record list.
Replay button opens the saved wave file.
11
12
Graph area shows the wave in real time.
13
Current area to indicate the big size showing data
14
Display button which can real time monitor temperature change.
7.2 System Requirements
Minimum requirements for the PC:
• Operating system:
• Communication:
To install DataTemp Raynger 3i Plus software you must log in with Administrator
privileges!
7.3 Software Installation
From the CD, launch the executing file to install the software on a computer. Follow the installation
wizard's instructions on the screen.
While installing the software, the USB driver for the instrument is installed
Automatically!
3i Plus
Windows XP, Windows 7, Windows 8
USB 2.0
Rev. A1 Jan 2015
Windows Software
