3 Technical Data

3.1 Measurement Specifications

Temperature Range
1M
2M
Spectral Response
1M
2M
Optical Resolution D:S
All models
System Accuracy
2
1M
2M
Repeatability
3
Temperature Resolution
Display
Exposure Time
Display Refresh Time
Emissivity
Signal Processing
at 90% energy in minimum and distance 4000 mm (157 in.)
1
Calibration geometry at ambient temperature 23°C ±2°C (73°F ±4°F), emissivity = 1.0
2
Calibration geometry at ambient temperature 23°C ±2°C (73°F ±4°F), emissivity = 1.0
3
3i Plus
700 to 3000°C (1292 to 5432°F)
400 to 2000°C (752 to 3632°F)
1.0 µm
1.6 µm
1
250:1
16 mm spot @ 4000 mm distance (0.63 in @ 157 in)
± (0.5% or reading + 1°C) for < 2700°C
± (0.5% or reading + 2°F) for < 4892°F
± 2% or reading for > 2700°C (4892°F)
± (0.5% or reading + 1°C)
± (0.5% or reading + 2°F)
± (0.3% or reading + 1°C)
± (0.3% or reading + 2°F)
± 0.1°C (0.1°F)
40 ms (95%)
200 ms
0.01 to 1.00
Max / Min / Avg / Diff
