Level <F1>
1 EMS
2

Profile

3 MnMx
4 Lock/Unlock
5 Setup
6 °C/°F
<Save> button

5.10.2 EMS - Emissivity

The <Emissivity> menu includes a list of pre-defined materials and their typical emissivity values, see
section 10.2 Typical Emissivity
To access the Emissivity menu:
1. Push the <Menu> soft key until EMS (emissivity) is shown as the right soft key function.
2. Push the <EMS> soft key.
The user can push the table soft key to access the emissivity list. The user can also push the <No.> soft
key to manually enter the typical emissivity of a material.
If the Emissivity table is accessed, a list of materials and their suggested emissivity is shown.
1. Use the down arrow to navigate through the list.
2. Push the <Done> soft key to choose the desired material.
To enter an emissivity value manually:
1. Push the <No.> soft key.
2. Use the down or up arrow soft key to change the entry. Hold down the up or down arrow soft
key to increase the rate of change.
3. Push the <Done> soft key when finished to return to the main menu.

5.10.3 Light

The instrument has a backlit display. The backlight can be toggled by pushing the <Light> soft key.
5.10.4 Profile
To manage regular testing points, different profiles can be created by the Raynger 3i Plus software.
Each profile includes the settings for Emissivity, Alarm Temperature, Transmissivity, Background
Temperature, etc., as well as a unique profile name. When the setting is ready, the user can simply
select the profile name to call up the settings, save data and review accordingly.
The maximum number of test points is 300. These test points are arranged in three levels, and the
maximum allowed for the second level is 50. The first and second levels could be represented by three
3i Plus
Description
Sets the emissivity value
Calls predefined profiles
Enables minimum/maximum
Locks/unlocks the trigger button
Time/Date, Alarm, Transmissivity,
Background Temperature, Bluetooth,
Language
Toggles between C and F
Save Reading to Memory
Table 3: Top-Level Menu Description
Values, page 56. The instrument's default emissivity value is 1.00.
Rev. A1 Jan 2015
<F2> <F3> Description
Menu Light Toggles the LCD backlit
Menu Trend Reviews recorded trends
Menu Avg Enables average/difference
Menu Laser Toggles the laser
Review/Delete recorded
Menu Log
temperatures
Menu Scope Toggles the red dot in the scope
<Return> button Back to Last Menu
Operation
23
