D4T/D4R
Parts and Accessories
Transmitter Power Supples
• Lectrosonics DCR12/A8U
(Replacement Power Supply)
Power Supply for D4T & D4R; 100-240 VAC, 50/60
Hz input; 12 VDC (regulated), 800 mA max. output.
• Lectrosonics DCR15/1A6U
Switching power supply with a universal socket
(IEC 60320 C13) on housing and locking plug;
90-240 VAC, 50/60 Hz input; 15 VDC, 1.6 A max.
output (regulated), 18 W. (Includes 21499 AC
power cord)
14
Receiver Power Supplies
• Lectrosonics DCR12/A8U
(Replacement Power Supply)
Power Supply for D4T & D4R; 100-240 VAC, 50/60
Hz input; 12 VDC (regulated), 800 mA max. output.
• Lectrosonics CH20
Transformer power supply with a 2-pin AC input
plug and a locking power output plug; 115 VAC
input, 12V DC regulated output; 500 mA max.
• Lectrosonics DCR15/1A6U
Switching power supply with a universal socket
(IEC 60320 C13) on housing,; 90-240 VAC, 50/60
Hz input; 15 VDC, 1.6 A max. output (regulated),
18 W. (Includes 21499 AC power cord)
AC Power Cord
• Lectrosonics 21499 Power Cord. 3-pin NEMA 5-15
plug (USA); for use with DCR15/1A6U
Not for use with
D4T transmitter
LECTROSONICS, INC.
