The table below lists the factory designated frequency
ranges available for the T5 IFB Transmitter.
Each T5 transmitter is built to cover a pre-selected range
of frequencies (a "block") as shown below. The transmit-
ter will tune to any of 256 different frequencies within this
factory assigned block.
The block number is determined by this formula:
25.6 × Freq. (MHz) = Lowest freq. (MHz) in the block
To determine a block number from a frequency:
Freq. (MHz) divided by 25.6 = Block number
It is handy to remember these formulas, in case you do
not have a copy of the table. For example, suppose you
need to know which block covers 685.500 MHz, without
using the table:
685.500 divided by 25.6 = 26.77734375
BLOCK
21
22
23
24
25
26
27
28
29
30
31
32
33

REPLACEMENT PARTS and ACCESSORIES

Part No.
21586
A500 RA B(block #)
10

FREQUENCY BLOCKS AND RANGES

FREQUENCY
RANGE
537.600 - 563.100
563.200 - 588.700
588.800 - 614.300
614.400 - 639.900
640.000 - 665.500
665.600 - 691.100
691.200 - 716.700
716.800 - 742.300
742.400 - 767.900
768.000 - 793.500
793.600 - 819.100
819.200 - 844.700
844.800 - 865.000
Description
DC16A Pigtail power cable, LZR to strip & tin
Antenna, flex
The first two digits left of the decimal are the block
number. In this case, 685.500 MHz falls within block 26.
The T5 IFB transmitter antennas are color coded to
indicate the frequency block that they operate within.
The length of the antenna varies with the frequency
block. The actual length of the antenna is not as critical
as it might appear in the table below. The usable band-
width of the A6U antennas are +/- 50 MHz from the
center frequency, so it is acceptable to use an antenna
from an adjacent block above or below the operating
frequency is some loss in range can be tolerated.
The color of the antenna sleeve is in keeping with
standard resistor value color codes for the second digit
of the block number.
ANT SLEEVE ANTENNA
COLOR WHIP LENGTH
Brown
Red
Orange
Yellow
Green
Blue
Violet (Pink)
Grey
White
Orange/Black
Orange/Brown
Orange/Red
Orange/Orange
4.74"
4.48"
4.24"
4.01"
3.81"
3.62"
3.46"
3.31"
3.18"
3.08"
2.99"
2.92"
2.87"
