6. Technical Data

CLX GM
Processor
Display
Interfaces
Terminal strips 12-way
Enclosure
Weight
Humidity range
Ambient humidity
Operating temperature
Dimensions (without screws and
mounting plate)
Power
Standby Power Consumption
32-bit microcontroller, 96 MHz
Display 4x20 LCD ASCII backlit
LAN (Ethernet 10/100 Mbit)
6 x digital inputs (self-powered), without galvanic isolation for exter-
nal floating contact
2-part, fanless metal enclosure for rail mounting (IP20)
330 g net (without accessories and external AC mains adapter)
< 80% non-condensing
Indoor/switch cabinet installation
Minimum 0 to 50 °C
160 mm x 100 mm x 31 mm (W x H x D)
12–30 VDC
Approx. 1 Watt
