3. Technical Description
3. Technical Description
3.1. Technical Description
3
1
Illustration 3.1: CLX GM Connectors (Bottom)
Legend
1
2
3
4
5 & 6
*) Not used.
Illustration 3.2: CLX GM Connectors (Top)
Legend
7
Micro SD slot: not used
6
2
3
Power supply with circular connector (12–30 VDC, 1 W)
Ethernet port for LAN
Not used
Input terminals, 12 lines:
2 x voltage (+)
6 x relay input (S01, S02, S03, S04, S05
4 x analog input 20 mA (A1+, A1-, A2+, A2-)
Not used
7
5
4
*)
*)
, S06
)
*)
L00410637-01_02
