E T C S o u r c e F o u r L E D Q u i c k G u i d e
I n s t a l l L e n s Tub e
Step 1:
Step 2:
Step 3:
I n s t a l l F i x t u r e
Step 1:
Step 2:
Step 3:
W A R N I N G :
Sou rc e Fo ur LED Pr of i le v 1. 3. 0 Qu ic k Gui de
Slide lens tube into shutter barrel.
Install the lens zoom knob.
Install the Phillips screw in the top of the lens barrel.
General use position
Hang or mount the fixture.
Attach safety cable.
Insert additional accessories such as a top hat, etc.
Use only hardware rated for total weight of fixture and accessories.
A safety cable (or other approved safety device) must be securely attached
to the safety cable loop before loosening the clamp.
Low clearance position
Page 2 of 7

Install Lens Tube
