1. Firstly, dump the dust, then clean dust bin
with a dust brush (refer to Fig 1).
2. Pope the blower up, then clean the air
inlet/outlet with a dust brush (refer to Fig 2
and Fig 3)
3. DO NOT clean the blower with water!
4. Pop the blower up, take out the filter, then
clean the dust bin itself in water (refer to Fig
4)
5. Clean the filter with a hairdryer or dust brush
(refer to Fig 5 and Fig 6)
6. After cleaning, assemble unit firmly, as it was
prior to being disassembled.
1. Force the locking bar forward
and raise the cover by right
thumb, then raise the rod of
the main brush with your left
hand (refer to Fig 1 and Fig 2).
2. Take out the main brush
(refer to Fig 3).
3. Insert the main brush into the
hole before closing the cover in
assembly.
Fig 1
Fig 3
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig 2
7
