Kogan KAVACROBVWA User Manual page 12

Decorative
Light
Decorative
Light Switch
Power
Indicator
Charging
Indicator
Signal
Transmitter
Positive and
negative
charging
electrodes
DC Socket
: only use gentle essences and oils in the decorative light. Harsh or abrasive
oils may damage the plastic surface. Damage caused by strong oils is not
covered by warranty.
Turn on the decorative light to create a relaxing atmosphere. A
small amount of essence can be poured into the light, which
will release a nice aroma once it has been warmed.
Press the switch to turn the decorative light ON/OFF.
The power indicator will light up when the docking station is
connected with power, or will go out when disconnected.
The indicator will flash when the vacuum is connected to the
dock and is being recharged.
The transmitted signal leads the vacuum back to the dock for
recharging. To get the best results, keep the transmitter clean
and not blocked by other objects.
The electrodes on the dock will match up to the electrodes on
the vacuum robot. To allow cleaning ensure that the area
around the electrodes is clear of obstacles that may cause
issues with the vacuum making a good connection.
The power DC socket is used to connect the output terminal
DC 24V on the adaptor to the charging station.
1. Decorative light
2. Decorative light switch
3. Power indicator
4. Charging indicator
5. Signal transmitter
6. Charging positive pole
7. Charging negative pole
8. DC socket
11
