Extended System Details
1) Standard Configuration
The unit is supplied built to order via the CTO system in the same way as existing MVS products. The
following is the default configuration:
SD format, 1M/E, 4RU Processor, 15 Inputs, 24 Outputs, SD Processing (480i/59.94, 576i/50)
- 1M/E, 1.5M/E, 2M/E and 2.5M/E are supported with the optional software. (For the required
optional software, please refer to section 3)
- Up to 4 control panels and 1 processor can be configured
- 1.5M/E and 2.5M/E can be configured with the simple P/P software, BZS-6250 (a new optional
item), which enables DME wipe as well on the simple P/P row
- Expandable up to 49 inputs with two MKS-8110G (an existing optional item) input boards
2) Upgrade to Multi-format Processing
It can be upgraded to multi-format with the upgrade software, BZS-6540M/6550M (new optional
items) 1080i/59.94/50, 720p/59.94/50, 480i/59.94, 576i/50 are supported.
Note: 1080psf and 1080i/60 are not supported; these formats are supported on the MVS-
8000G/GSF.
