Main Features

1) Compact and Versatile HD-ready Switcher

The compact 4RU processor includes a newly developed ASIC (Image Processor). The new processor
is responsible for image processing, resizer and keyer functions and results in an 80% power
reduction when compared to the MVS-8000GSF.
The standard configuration of the unit is for SD operations. It can be easily configured for multi-
format operation by installing a simple software update. When using both HD and SD signals, an
optional internal format converter board is available allowing users to seamlessly mix different signal
types in a single production.

2) Fixed Configuration Control Panel (CCP-6224, CCP-6324)

Two new control panels are also available for the MVS-6000. The 2M/E, 24-crosspoint button (CCP-
6224) and 3M/E, 24-crosspoint button (CCP-6324) panels come with a fixed layout and can be
ordered as a single item. These same panels can also be used with the MVS-8000G/GSF and DVS-
9000/SF switchers.
By having a fixed configuration, it allows for standardization resulting in reduced manufacturing
costs. The new combined Multi Function Flexi-pad module reduces the number of modules by
combining the functionality of multiple modules into a single module. The fader for Key frame can
be assigned to a transition fader. The AUX bus can be controlled on the M/E row and the AUX bus
row module can be removed. It is also possible to use the system with a standard computer monitor
and mouse to instead of the menu panel, but if customers wish to use the traditional touch-screen
menu panel this is also possible.
CCP-6224 :
7 |
