Crestron TPMC-8X-GA
Operations Guide – DOC. 7078E

Specifications

Specifications for the TPMC-8X-GA are listed in the following table.
TPMC-8X-GA Specifications
SPECIFICATION
Touch Screen Display
Display Type
Size
Aspect Ratio
Resolution
Brightness
Contrast
Color Depth
Illumination
1
Viewing Angle
Touch Screen
Memory
DDR2 SDRAM
Flash
Memory Card
Maximum Project Size
2
Graphic Engine
Embedded PC Applications
Wireless Communication
Transceiver
Range
Gateway
Roaming
(Continued on following page)
®
Isys 8.4" WiFi Touch Screen
TFT active matrix color LCD
8.4 inch (213 mm) diagonal
4:3 SVGA
800 x 600 pixels
200 nits
500:1
18-bit, 262k colors
Edgelit fluorescent with auto-brightness
±65º horizontal, +65º/-45º vertical
Resistive membrane
1 GB
4 GB
Accepts up to 32 GB MMC compatible card
(not included)
190 MB
Core 3 UI, 16-bit color depth (non-palette),
®
VT Pro-e programmable, supports Core 3
projects
3
Microsoft Internet Explorer with Adobe
Flash plug-in and Java Runtime plug-in,
Windows Media Player, Crestron VNC
4
Viewer , Remote Desktop, Adobe Acrobat
Reader, WordPad, MS Word Viewer 2003,
Excel Viewer 2003, PowerPoint Viewer
2003
3
IEEE 802.11a/b/g Wi-Fi, 5.8 or 2.4 GHz
2-way RF, static IP or dynamic IP via
DHCP, 64 and 128-bit WEP encryption
Up to 80 feet (~24 meters) omnidirectional
using 802.11b/g, 35 feet (~11 meters)
omnidirectional using 802.11a, @ 54 Mbps;
range and speed vary based upon
environmental conditions
Requires a CEN-WAP-ABG-1G,
CEN-WAP-ABG-CM or similar 802.11a/b/g
wireless access point and Ethernet enabled
Crestron control system (all sold
separately)
Requires a Cisco
installed and commissioned by a Cisco
certified technician
®
8.4" WiFi Touch Screen: TPMC-8X-GA • 5
Isys
DETAILS
®
controller solution to be
