Capturing snapshots

The snapshot feature, which is disabled by default, allows
snapshots captured by your video system to be displayed
on the Call Control page. Captures from your video system's
camera as well as from its presentation channel will be
displayed.
This feature might come in handy when administering the
video system from a remote location, e.g. to check the
camera view.
To use web snapshots you have to sign in with ADMIN
credentials.
Enabling the snapshot feature
The snapshot feature is disabled by default. The feature must
be enabled using the remote control and on screen
• Go to the Advanced configuration menu, navigate to
Video > AllowWebSnapshots and choose On.
Far end snapshots while in a call
While in a call, snapshots of the remote participant's main
camera and presentation channel (far end) will be captured
and displayed as shown in the illustration. The snapshots are
updated approximately every 20 seconds.
Far end snapshots are captured even if web
snapshots are disallowed on the far end video
system. Web snapshots are prohibited only for
encrypted calls.
D14637.10 Profile C20 and Quick Set C20 Administrator Guide TC6.1, APRIL 2013.
Introduction Web interface Web interface
Navigate to: Call Control > Call Control
menu.
System settings
www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
20
Administrator Guide
Setting passwords Appendices
Far end snapshots
Take live snapshots
While the Live snapshots
snapshots are captured by your video system (main
camera and presentation) approximately every two
Snapshots from your video system
box is checked,
seconds.
