Controlling and monitoring a call

You can control and monitor several call features using the
Call Control page.
D14637.10 Profile C20 and Quick Set C20 Administrator Guide TC6.1, APRIL 2013.
Introduction Web interface Web interface
Navigate to: Call Control > Call Control
Microphone
mute
Click the button
to mute the
microphone.
Then the text
changes to
Microphone:
Click again to
unmute.
System settings
Off.
17
Setting passwords
Volume down
www.cisco.com — Copyright © 2010-2013 Cisco Systems, Inc. All rights reserved.
Administrator Guide
Appendices
Volume up
Show/hide
call details
Click the arrow
to show details
about the call.
Click the arrow
again to hide the
information.
Call details
If necessary,
scroll your browser to
see the call details.
