Matrix Installation and Operation Instructions
Table 9.4 Matrix Boiler Control Programming
Menu Level
Main Value
RUN
HYD 80-200
HI 80-200
DIF 1-40
RES 70-HI
SFS 75-100
HFS 100-240
LFS 46-100
FrE ON/OFF
Sto OFF-24
To start the control operation, you must return to RUN on the menu, and press Function. Normal
operation will begin. Controller will return to RUN mode if no button is pressed for 2 minutes.
9.2.2 Setting Matrix Fan Control
Just as the Matrix Boiler Controller controls all of the operation and safety functions of the boiler, the Matrix Fan Controller,
controls all of the operation and safety functions related to air handling and hot water dispatching. The fan controller controls the
forced air modulation,
systems.
Table 9.5 Matrix Fan Control Programming
Menu Level
Main Sub Value
RUN
OFF
HRV
ON
PF1
HEA PF2
PF3
Y1 40-Y2
Y2 Y1-160
FAN 40-160
SCL 30-100
ECL 30-100
SCH 30-100
ECH 30-100
BAL
SOL 30-100
EOL 30-100
SOH 30-100
EOH 30-100
H2O 100-160
rAd 1 or 2
To start the control operation, you must return to RUN on the menu, and press Function. Normal
operation will begin. Controller will return to RUN mode if no button is pressed for 2 minutes.
Program Mode - When Run is displayed controller
is in 'Prog' mode. Arrow up or down to scroll
through menus
Hydronic Call Setpoint
Auxiliary Heat Setpoint – prior to outdoor reset
adjustment
Differential Setting - Applies only to Hydronic Only
setpoint. Temperature difference below setpoint at
which burner will re-light.
Sets Outdoor Reset Curve Slope – See
Determining Reset Temperature for more
information.
Starting Gas Input Value
Maximum Gas Input Value
Minimum Gas Input Value
Freeze Protection – Operates burner and circulator
if temperature drops below 40ºF.
Storage Feature Timer – Length of time in hours
storage feature will keep boiler hot.
ventilation, as well
Default
When Run is displayed, controller is in 'Prog' mode. Arrow up or down to scroll
through menus
HRV Mode – Always off unless call for high ventilation (DH)
HRV Mode – Continuous Ventilation. HRV will exchange air at low ventilation
ON
rate during a call for forced air heat (W1 or W2) or continuous circulation (G).
Will increase to high ventilation rate with a high ventilation call (24vac @ DH)
Heat Profile 1 400 to 1000CFM; 50,000 Btu/h max.
PF1 Heat Profile 2 400 to 1100CFM; 77,000 Btu/h max.
Heat Profile 3 400 to 1200CFM; 105,000 Btu/h max.
80 Stage 1 AC/HP Flow x 10 = CFM, settable from 400 up to Y2 (1600 max).
120 Stage 2 AC/HP Flow x 10 = CFM, settable from Y1 (400 min) up to 1600.
40 Fan circulation rate (G) x 10 = CFM, settable from 400 to 1600.
60
60
60
60
HRV Balancing – (see HRV section for more details)
100
100
100
100
125 Set point for desired DHW temperature in degrees Fahrenheit.
Determines the anticipated supply plenum size. For units with the 20x16" Supply
2
Plenum, set to 1. For units with the 22.5x18.5" Supply Plenum, set to 2.
Description
as priority of domestic
Description
35
Typical Settings
100-120 Infloor (High Mass)
140-160 Infloor (Low Mass)
140-160 Fan Coil
190
10
85
80
240
48 (min 46)
ON
2
hot water and secondary heating
