This Boiler must be installed by a licensed and trained Heating
Technician; otherwise the warranty of this unit is void. Failure
to properly install this unit could cause damage to property
and injury to occupants possibly resulting in death.
1.0 SPECIFICATIONS ..................................................................................................2
2.0 INSTALLATION REQUIREMENTS ...................................................................2
3.0 VENTING .................................................................................................................4
4.0 CONDENSATE DRAIN ..........................................................................................9
5.0 INSTALLING GAS PIPING...................................................................................9
5.0 INSTALLING GAS PIPING.................................................................................10
......................................................................................................10
6.0 HEATING SYSTEM PIPING...............................................................................12
6.2.1 Multiple Zones using Zone Valves .............................................................16
6.2.2 Multiple Zones using Pumps......................................................................16
6.2.3 Multiple Zones with Different Temperatures ............................................17
7.0 WIRING ..................................................................................................................20
7.2.1 Multiple 4 wire Zone Valves.......................................................................22
7.2.2 Multiple Zones with Taco Valve controller................................................23
7.2.3 Multiple Zones Pump controller ................................................................24
7.2.4 Multiple Temperature Zones with Injection Pumps..................................25
8.0 SENTRY 2100 CONTROLLER ...........................................................................26
9.0 LIGHTING BOILER.............................................................................................30
-
.................................................................................................30
-
...............................................................................................30
.................................................................................................30
10.0 TROUBLE SHOOTING......................................................................................31
11.0 SEQUENCE OF OPERATION ..........................................................................34
14.0 ANNUAL MAINTENANCE AND INSPECTION............................................36
15.0 PARTS LIST.........................................................................................................37
CAUTION:
IT IS THE RESPONSIBILITY OF THE HOMEOWNER TO
KEEP THE VENT TERMINAL CLEAR OF SNOW AND ICE.
..................................................................................2
............................................................................................4
.........................................................................7
..........................................................................................7
........................................................................................10
...................................................................................13
..................................................................16
...................................................................................18
......................................................................21
..............................................................................22
...................................................................36
Trinity Ti
Trinity Ti Boiler Only
VERSION DATE: 1-5-2010
Installation and
Operation Instructions
Advertisement
Table of Contents
Related Manuals for NTI Trinity Ti 100
Summary of Contents for NTI Trinity Ti 100
-
Page 1: Table Of Contents
This Boiler must be installed by a licensed and trained Heating Technician; otherwise the warranty of this unit is void. Failure Trinity Ti to properly install this unit could cause damage to property and injury to occupants possibly resulting in death. Trinity Ti Boiler Only VERSION DATE: 1-5-2010 Installation and... -
Page 2: Specifications
1.0 SPECIFICATIONS Description Ti 100 Ti 150 Ti 200 Ti 400 Input (BTUx1000) Natural =100 / 15 Natural =150 / 25 Natural = 200 / 25 Natural = 399 / 75 Input Capacity - Max. / Min. Propane= 100 / 15 Propane= 145 / 25 Propane= 194 / 25 Propane= 399 / 75... - Page 3 “In the State of Massachusetts only” (a)For all horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned and operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS.
-
Page 4: Venting
2.1 Location In all cases, the Trinity boiler must be installed indoors, in a dry location, such that the gas components are protected from dripping or spraying water or rain, during operation and servicing. The boiler location ambient temperature is maintained to a minimum of 50°F. Determine the best location of the vent termination, and if possible locate the boiler as close to the termination point as possible. - Page 5 3.2.2 Concentric Vent Termination (No longer approved for Canada) • Ti100-200 Only (Not for use with Ti400) • NTI part number 82666 (York part number 1CT0303) • Instructions included with vent terminal contain more detailed assembly and installation instructions. •...
- Page 6 3.2.3 Ti400 Optional Vent Termination Kit Window • NTI part number 83236. • For use with Ti400 only. • 4” Connections (When venting with 6”, must adapt down at terminal) • See Installation Manual included in vent terminal kit for further instructions.
-
Page 7: Venting Rules And Guidelines
2. Air for combustion must be drawn from outdoors from an area free of dust and contaminants. Combustion air containing chemicals such as chloride, fluoride, bromine or iodine, will cause corrosion damage of the heat exchanger voiding your NTI warranty. Avoid drawing combustion air from the vicinity of swimming pools, laundry facilities, workshops, or other areas where the air may contain chemicals or dust. - Page 8 Within 6’ of a mechanical air supply inlet to any building, or roof eve containing soffit openings. Above a meter/regulator assembly within 3' horizontally of the vertical centerline of the regulator. Within 3' horizontally of any gas service regulator vent outlet up to a height of 15’. Less than 30”...
-
Page 9: Condensate Drain
4.0 CONDENSATE DRAIN Warning This unit produces water as a product of combustion. Much of this water condenses on Failure to properly connect the condensate the heat exchanger and in the venting system. line will cause combustion gases to enter the All exhaust piping must be on a slope back to room, possibly causing serious injury to the boiler ¼”... -
Page 10: Installing Gas Piping
5.0 INSTALLING GAS PIPING Ti100-200 5.1 Installation Refer to the current National Fuel Gas Code ANSI Gas valve Z223.1/NFPA 54 or CAN/CGA B149.1 installation codes, and local codes for gas piping requirements and sizing. Pipe size running to the unit depends on: •... - Page 11 8% (9% for LP Gas). If the CO is over 140 PPM and the CO is less than 8% (9% for LP Gas), contact NTI for assistance. CO – At minimum fan speed, should be checked, and the CO should be less than the reading recorded at high fan speed. The CO...
-
Page 12: Heating System Piping
Install fittings that will allow the system to be flushed if needed during annual check-ups. Add inhibitor, Fernox Protector F1 (NTI Part Number: 83448), to the system water to help prevent limestone and magnetite deposits and galvanic corrosion. Bottle provided will treat an average 100-liter (26 US gallon) system. -
Page 13: Primary Loop Plumbing
The Trinity boiler comes in two versions, Heating and Combi. Heating Version – The standard heating version is designed to operate in a hydronic heating system and can operate with an indirect water heater. Combi Version – This special version is equipped with internal components to provide hydronic heating and domestic hot water heating. See Sections 6.1 and 6.3. - Page 14 • Models Ti100-200 A certified LWCO or Flow Switch is not provided in the package, however one is to be field installed in any application where the boiler is located above the radiation or where local authorities require it. NTI recommends installing a LWCO or flow switch to prevent the boiler from firing without water in the heat exchanger.
- Page 15 Primary Loop For Heating Model Ti 100-150 Legend Quantity and location of shutoff valves, and drains, are at the discretion of the installed. non ASME) A- Back flow preventor B- Fill valve (set at 12 psi) C- Diaphragm expansion tank D- Cast Iron Air scoop, for excessive air use Spirovent (see page 12).
-
Page 16: Secondary Loop Heating System
6.2 Secondary Loop Heating System The following are typical piping systems. It is the responsibility of the installing contractor to determine which system best meets the need of the installation. Contractor modifications to these instructions may be required, based upon existing piping and system design. 6.2.1 Multiple Zones using Zone Valves Max. -
Page 17: Multiple Zones With Different Temperatures
6.2.3 Multiple Zones with Different Temperatures Using pumps and tempering valves Max. 12” apart Primary Loop See figure Tempering valve 7.2.3 “Multiple Zones using pumps, and pump controller” Zone 1 By setting the tempering valves to different Low Temp. settings, multiple temperatures can be obtained. -
Page 18: Domestic Combi System
External Combi Manifold, diverting valve, shown, refer to labels on plate heat exchanger & flow switch. Note: boiler, contact NTI with any The installer is required to install the pump questions. flange (included in Combi kit) onto the boiler return pipe prior to installing the boiler;... - Page 19 To combat delays in domestic hot water delivery, normally associated with on-demand hot water heaters, Trinity Combi boilers are equipped with an optional “Storage Mode” feature, which when turned on via the Sentry menu, maintains hot domestic water at the plate heat exchanger for 1 to 24 hours after the latest DHW call ended (Sentry menu option StO is adjustable from OFF to 1 to 24 hours, factory setting is 4).
-
Page 20: Wiring
Table 1: Ti150C Flow rates (flow rates in usgpm) Inlet Water Temperature (deg. F) Table 2: Ti200C Flow rates (flow rates in usgpm) Inlet Water Temperature (deg. F) To avoid having too much flow at your faucets use the shut off valve after the mixing valve to limit the overall flow of domestic hot water. -
Page 21: Simplified Wiring Connections
7.1 Simplified Wiring Connections Heat and Indirect Wiring Indirect 120V WIRING Aquastat Outdoor Probe Primary Pump CAUTION White Contacts that energize * Indirect Black these inputs Circulator MUST BE DRY CONTACTS ONLY 120/1/60 15 AMP FUSED Electrical Box POWER SUPPLY 5V WIRING Combi Wiring 120V WIRING... -
Page 22: Advanced Wiring Systems
7.2 Advanced Wiring Systems 7.2.1 Multiple 4 wire Zone Valves Legend Blue P1- Primary Pump P3 - Secondary pump P2- Indirect pump, or CB - Trinity Control box Combi Valve *R – 120V Relay Coil *R1 - Relay Contact * Only required with Combi boiler. White Purple Burner On... -
Page 23: Multiple Zones With Taco Valve Controller
7.2.2 Multiple Zones with Taco Valve controller (Models ZVC403 to ZVC 406) Legend P1- Primary Pump CB- Trinity Control box P2- Indirect pump, or Combi Valve Burner On Heating Pump Aux. Pump Call for Heat %Ef. Water 120/1/60 15 AMP FUSED POWER SUPPLY The basic multiple zoned system using normally closed 2 –... -
Page 24: Multiple Zones Pump Controller
7.2.3 Multiple Zones Pump controller (Models Taco SR504, Argo ARM 861 Series) Legend P1- Primary Pump CB- Trinity Control box P2- Indirect pump, or Combi Valve Indirect thermostat, or combi flow switch The basic multiple zoned system using circulating pumps. This wiring system is used with the piping as described in 6.2.2 Multiple Zones using Pumps and 6.2.3 Multiple Zones with different temperatures. -
Page 25: Multiple Temperature Zones With Injection Pumps
7.2.4 Multiple Temperature Zones with Injection Pumps (Models Taco SR504, Argo ARM 861 Series And Tekmar 356 controller ) Indirect thermostat, or combi flow switch Loop 1 (Hi Temp.) Thermostat, or manifold end switch Loop 2 (Lo Temp.) Thermostat, or manifold end switch Legend P1- Primary Pump... -
Page 26: Sentry 2100 Controller
Once the room thermostat is satisfied, it breaks power to the TT terminal of the pump controller, which opens the X –X contacts, which opens the T-C circuit. The Pumps and burner turn off. In an injection system, it is important to understand the effect of flow and temperature set points. It may be necessary to program the Sentry controller higher than the desired Mix temperature of the Hottest Loop. - Page 27 8.2 Sentry 2100 Operation The Trinity boiler employs a pneumatic modulation system. This modulation system increases or decreases the velocity of the blower, to meet the demand for heating. The gas valve, senses this change, in blower pressure, and introduces the required amount of gas, to ensure correct combustion.
- Page 28 8.3.1 Sentry 2100 Menu Menu Settable Description Typical Settings Item Range Program Mode - When Run is displayed, controller is in ‘Prog’ mode. Arrow up or down to scroll through menu items. DHW Set Point – Boiler temperature the control 80-190ºF attempts to maintain during a domestic hot water call 160ºF...
- Page 29 8.3.2 Calculating Outdoor Reset Curve (RES) Formula: Operating Temperature (HI ) = {(RES – Outdoor Temp) x (HI – RES) / RES} + RES CALC. Example: • There is a call for heat and no call for domestic hot water (T-C closed & A-C open), the control uses the programmed HI and RES settings and the current outdoor temperature.
-
Page 30: Lighting Boiler
9.0 LIGHTING BOILER 9.1 Initial Start-up • Ensure that the boiler is wired in accordance with this manual. • Ensure that the gas shut-off valve is turned on, and that the gas system has been fully tested for leaks. • Ensure that the system is completely filled with water, and that ALL the air is purged out. -
Page 31: Trouble Shooting
Solution 1 – If the boiler is extremely hot check for adequate water pressure and circulation, “Water Temperature contact NTI for assistance. Excessive” 2 – If not hot, check for sources of grounding or shorting at the Water Sensor electrical... - Page 32 2 - Boiler may be plugging-up with scale or magnetite, clean with Fernox DS-40 or hisses running indicates Descaler and Cleanser (NTI PN: 83450). insufficient flow 3 - If glycol is being used the concentration may be to high, recommend using a concentration lower then 35%.
- Page 33 Ensure that the venting lengths are in compliance with Section 3.4 Ensure that the line pressure during operation does not drop more than 20% from the static line pressure. Boiler Lights Typically an imbalance in Momentarily remove the intake vent from the boiler during ignition, if unit lights rough or the Air to gas ratio smoothly with intake vent disconnected reconnect and check for proper combustion if...
-
Page 34: Sequence Of Operation
11.0 SEQUENCE OF OPERATION The following is the normal sequence of operation for the trinity boiler. Trinity Sequence of operation 120v Power Displays version Boiler in Applied t2.0 or t4.0 standby mode Indirect thermostat Thermostat, End switch or flow switch closes A-C or relay closes T-C Energizes Combi... - Page 35 12.0 WIRING SCHEMATIC...
-
Page 36: Annual Maintenance And Inspection
13.0 INSTALLATION CHECKLIST Installation a) Connect all plumbing, and ensure that there are no system leaks, add Fernox F1 Protector (NTI PN: 83448). b) Connect, secure, and glue all vent piping. c) Install all gas piping as per this manual, and local codes. Pressure test, to detect any gas leaks. -
Page 37: Parts List
15.0 PARTS LIST Models Ti100-Ti200 Replacement parts are available from your stocking wholesaler. Homeowners must contact their local Installer or Wholesaler. Installers or Wholesalers may contact NY Thermal Inc. for assistance at 506-432-1130. Notes: *Used for Combi version only. P. N. De scription 82 657 Premix burner , 135. - Page 38 Model Ti400 P.N. Description Premix Burner NIT 327 (For Ti400) 83173 82761 Premix Burner Gasket 82457 Transformer, 24V Sentry 2100 Assembly 83171 EBM BLOWER #RG148/E 82994 Gas Valve VR8615VB 1044B 82989 Gas Valve Adapter, 3/4" NPT 82991 Gas Valve Connector O-ring 83194 83016 Gas Valve Harness...
