Matrix Installation and Operation Instructions
Call for Heat (24VAC @ W1): Normal Thermostat call, Matrix operates as a step-modulating furnace as described above. If
HRV set to 'ON', HRV will operate at the low (continuous) ventilation rate.
Call for Auxiliary Heat (24 VAC @ W2): When calling, furnace will provide heat at a stage 10 output rate. With a call for
auxiliary heating the Matrix will function as a single stage, full fire appliance. This means the burner will come on with a
thermostat call and go off when the call is satisfied. If HRV set to 'ON', HRV will operate at the low (continuous) ventilation rate.
Outdoor Sensor: The auxiliary heating function (24VAC @ W2) will utilize the outdoor sensor if available. The outdoor reset
function is not used for W1 heating. This function is also active during a hydronic heat demand (24VAC @ H).
Plenum Sensor: The Matrix is equipped with a plenum temperature sensor that must be field installed in the supply plenum and
wired to the furnaces external terminal strip. When installed the Matrix fan control displays the plenum temperature and will use it
to detect problems in the supply of heat to the space.
Call for Circulating Fan (24VAC @ G)
in the Fan (blue) controller (400-1600 CFM)
(Continuous) ventilation rate.
Call for Dehumidification (24VAC @ DH)
ventilate at the high (Override) ventilation rate.
Call for Cooling Fan (24VAC @ Y1): Matrix operates at the prescribed air circulation rate (Y1x10 CFM – See 8.2 Fan
Control). HRV will not operate during a call for cooling unless there is a concurrent call for DH – Dehumidification or G –
Continuous and HRV is set to ON.
Call for Cooling Fan (24VAC @ Y2): Matrix operates at the prescribed air circulation rate (Y2x10 CFM – See 8.2 Fan
Control). HRV will not operate during a call for cooling unless there is a concurrent call for DH – Dehumidification or G –
Continuous and HRV is set to ON.
10.2 Duct Sizing
When sizing ductwork, a maximum flow velocity of 800 fpm is
desired. Table 11 shows common duct sizes at specified flows. The
maximum flows that can be expected are shown in Table 10.3. It is
important to maintain the return plenum pressure as low as possible.
Keeping this ductwork as free flowing as possible will offer more
supply static pressure to overcome A/C coils, closed registers etc while
maintaining constant flow.
Any additional filtration, humidification, or de-humidification
equipment should be installed external to the return or supply ducts so
not to create additional restriction.
Table 10.2 Duct Size vs. Air Flow
Airflow
Area
(CFM)
(sqft)
1600
2
24x12
1200
1.5
24x10
1000
1.25
800
1
Based on 800 fpm max airflow velocity
Matrix operates at the programmed air circulation rate according to the "FAN" setting
:
.
If HRV is set to 'ON' (See 8.2 Fan Controller), the HRV will ventilate at the low
Matrix operates at the minimum air circulation rate (400 CFM)
:
Duct Sizing
(inches)
20x16
20x12
18x12
20x10
18x10
16x12
18x8
16x10
Table 10.3 Maximum Air Flow Rates
Fan Control Setting
Heating
(HEA)
PF3
PF2
PF1
Example #1 No cooling function with Heating
profile of PF2 selected. Maximum airflow will be
1100 CFM.
Example #2
cooling with Heating profile of PF3 selected.
12x12
Maximum airflow will be greater of cooling or heating
function. Maximum 1200 CFM.
*Measured from return plenum to supply plenum prior to A/C coil.
ECM motor can produce near constant flow provided horsepower or
maximum speed of motor is not exceeded.
38
Cooling
ESPmax*
(COO)
160 max
.35 inwg
160 max
.6 inwg
160 max
.75 inwg
120 (3 Ton)
80 (2 Ton)
No Cooling
<1 inwg
No Cooling
<1 inwg
No Cooling
<1 inwg
Cooling set to 800 CFM for 2 tons of
.
HRV will
CFM
1600
1500
1400
1200
800
1200
1100
1000
