HP ProCurve Switch xl Modules
Installing the Modules
22
Customizing the Port Configuration
If the slot in which you installed the module was empty the last time the switch
was either rebooted or reset (or the power to the switch was cycled), then the
module will use preconfigured default parameter values that will work for
most networks.
The default port configurations for connection parameters are:
Ports Enabled: Yes
Mode:
•
10/100-TX xl Module: Auto — The port auto negotiates speed (10
or 100 Mbps), communication mode (half or full duplex), and MDI or
MDI-X port operation. Note: if you configure the port to one of the
fixed 100 Mbps modes, the port will then operate only as an MDI-X
port.
•
100/1000-T xl Module: Auto — The port auto negotiates speed (1000
or 100 Mbps), communication mode (half or full duplex), and MDI or
MDI-X port operation. Note: if you configure the port to one of the
fixed 100 Mbps modes, the port will then operate only as an MDI-X
port.
•
Gigabit-SX, Gigabit-LX, and Gigabit-LH ports in mini-GBIC xl
Module: Auto — The port always operates at 1000 Mbps and full
duplex. The setting is Auto for best link establishment with other
devices.
•
100-FX MTRJ xl Modules: 100FDX — The port operates at 100
Mbps and full-duplex.
•
10/100/1000-T xl Modules: Auto — The port auto negotiates speed
(10, 100 or 1000 Mbps), communication mode (half or full duplex),
and MDI or MDI-X port operation. Note: if you configure the port to
one of the fixed 100 Mbps modes, the port will then operate only as
an MDI-X port.
Dual Personality ports - (mini-GBIC ports using Gigabit-SX,
Gigabit-LX, and Gigabit-LH ports): Auto — The port always
operates at 1000 Mbps and full duplex. The setting is Auto for best
link establishment with other devices
Flow Control: Disabled
Advanced features — Spanning Tree, Trunking, Meshing, VLANs, IGMP,
LACP, Routing, Class of Service, Security, and so forth: all Disabled
