HP ProCurve Switch xl Modules
Descriptions
HP ProCurve Switch
PoE xl Module
2
PoE
(J8161A)
hp procurve
xl module
HP ProCurve Switch
10/100/1000-T xl
3
Module (J4907A)
The following HP ProCurve mini-GBICs are supported by the 10/100/1000-T
xl Module (as of this printing): • Gigabit-SX LC mini-GBIC (J4858A) • Gigabit-
LX LC mini-GBIC (J4859A) • Gigabit-LH LC mini-GBIC (J4860A)
• The Gigabit 1000Base-T mini-GBIC (J8177B) is not supported on the
10/100/1000-T xl Module (J4907A).
HP ProCurve Switch
Access Controller xl
4
Module (J8162A)
Due to power consumption, no more than two
N o t e
J8162As are supported in the chassis at a time.
This product contains a Lithium coin-type battery (type CR2032) that requires
WA R N I N G
special handling at end-of-life. The battery can explode or cause burns if
disassembled, charged, or exposed to water, fire or high temperature. After
replacing the battery, properly dispose of used battery.
1
This module requires switch software version E.07.01 or later to be installed in the switch.
2
This module requires switch software version E.08.20 or later to be installed in the switch.
3
This module requires switch software version E.08.42 or later to be installed in the switch.
4
This module requires switch software version E.09.2x or later to be installed in the switch.
Contact your HP-authorized networking products reseller or your HP representative for information
on availability of other modules and mini-GBICs. You can also visit the HP networking products
http://www.hp.com/go/procurve
web site
2
Module
LED Mode
PoE
EPS
Std
PoE
Status
Link
1
Mode
2
3
4
5
6
PoE
J8161A
7
8
9
10
11
12
to get more information.
PoE-Ready 10/100-TX Ports (1-24) – all ports are HP Auto-MDIX
13
14
15
16
17
Link
18
Mode
xl
module
19
20
21
22
23
24
Description
24 10/100-TX ports and when
connected to an HP ProCurve
600 Redundant and External
Power Supply (J8168A), can
provide Power over Ethernet
(PoE) power to 802.3af
compliant devices.
14 twisted-pair ports with RJ-45
connectors for 10/100/1000
Mbps (Gigabit) or 100 Mbps
operation over Category 5 or
better 100-ohm UTP or STP
cable (category 5e
recommended for Gigabit) -- all
ports have the IEEE 802.3ab
Auto MDI/MDI-X feature, and 2
slots for installing any sup-
ported ProCurve mini-
GBICs.
There are no ports on the
J8162A. It operates as a
wireless access controller.
Wireless traffic is directed to
this module using VLAN's. For
configuration information see
your HP ProCurve Series
5300xl Switches Installation
and Getting Started Guide,
Chapter 3, "Getting Started
with Switch Configuration".
