TVLogic LVM-071W User Manual page 8

· [MENU] button
Used to activate the OSD menu.
· [UP] button
Used to navigate menu during OSD menu activation. It may also be used to toggle
clockwise through 1:1 quadrants in native scan mode.
· [DOWN] button
Used to navigate menu during OSD menu activation. It may also be used to toggle
counterclockwise through 1:1 quadrants in native scan mode.
· [ENTER] button
Used to confirm a chosen value (or mode) within the OSD menu.
· [POWER] switch
Power On/Off button. If the signal is normal, LED lights in Green. If the signal is unsup-
ported or disconnected, LED flashes in Yellow.
· TALLY
LED indicating monitor's current status using optional Remote/RS-485.
· [APERTURE] knob
Used to adjust the picture sharpness between MAX(12) and MIN(-12).
#Aperture is not available in DVI Analog mode.
· [BRIGHT] knob
Used to adjust the degree of brightness between MAX(25) and MIN(-25).
· [CHROMA] knob
Used to adjust the saturation between MAX(25) and MIN(-25).
#Chroma is not available in DVI Analog mode.
· [CONTRAST] knob
Used to adjust the contrast ration between MAX(25) and MIN(-25).
· [VOLUME] knob
Used to adjust the volume between MAX(20) and MIN(0).
7
