<FRONT>
· [ANALOG] button/lamp
Used to select desired Analog Input. (CVB1/2/3, S-Video, Component, RGB)
· [DVI] button/lamp
Used to select desired DVI Input. (DVI DIGITAL, DVI ANALOG)
· [SDI] button/lamp
Used to select SDI Input.
· [UNDERSCAN] button/lamp
Used to transfer from OVER SCAN mode to UNDER SCAN mode.
Mode changes in the order of UNDERSCAN -> OVERSCAN -> PIXEL TO PIXEL ->
UNDERSCAN.
#PIXEL TO PIXEL mode is not available in Graphic mode.
· [ASPECT] button/lamp
Used to toggle aspect ratio in SD from standard to anamorphic.
· [MARKER]/[HVDELAY] button/lamp
Used to show MARKER on the screen. The type of marker at work may be selected on
the main menu. Press and Hold the button to activate the HV Delay mode.
· [BLUE ONLY]/[MONO] button/lamp
You may remove R(red) and G(green) from the input signal and play the screen only
with B(blue) signal. Button may be pressed twice to change the screen to MONO
mode. (This mode uses only Luminance value.)
· [PHASE] button/lamp
Used to change the Phase values.
#Phase is not available in DVI Analog and PAL mode.
· [WAVEFORM]/[VECTOR SCOPE] button/lamp
Used to activate the Waveform or Vector Scope. Pressing the button once will activate
the Waveform, pressing the button twice activates the Vector Scope.
