Altronix AL642ULADA Installation Manual page 4

5. Set output selection switches marked [OUT1 through OUT4] to follow corresponding input [IN1 & IN2]
and desired output signal type (Output Programming Selection Table, pg. 4).
6. Connect FACP output to desired AL842LGK logic board inputs, and notification appliances to desired AL842LGK
logic board outputs (see 42 Application Guide).
Note: The 2-wire horn/strobe sync mode will only synchronize horns, horn/strobes, strobes with
synchronization capability.
7. For connection of smoke detectors, digital dialer (see Hookup Diagram, pg. 7).
Output Programming Selection Table:
Outputs must be programmed independently (OUT1 - OUT4)
Function
Input to Output Follower Mode
Temporal Code 3 Mode
Steady Mode
For the above modes Dip Switch 4 determines which Input controls the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by input 1.
Switch 4 in the OFF position causes output(s) to be controlled by input 2.
Note: It is required to control visual notification appliances (strobes) via input 1 (IN1)
and audible notification appliances (horns) via input 2 (IN2). This allows audible
notification appliances (horns) to be silenced while visual notification appliances (strobes) continue to operate.
The FACP must be capable of a visual annunciation to the silencing status of the output or zone(s) to which the
AL642ULADA (NAC Power Extender) is connected.
Switch Positions
Function
ON
Amseco Sync 1, 3,
Mode*
Faraday
2, 4
Sync Mode*
Gentex ®
1, 2,
Sync Mode*
3, 4
Gentex is a registered trademark of
Gentex Corporation.
System Sensor
®
Sync Mode*
1, 2, 4
System Sensor is a registered
trademark of Honeywell.
CooperWheelock ®
Sync Mode*
2, 3, 4
CooperWheelock is a
registered trademark of
CooperWheelock.
- 4 -
Switch Positions
ON
1
3
Sync Mode Selection Table:
Descriptions
OFF
This mode is designed to work with the Amseco series of horns, strobes, and
horn/strobes to provide a means of synchronizing the Temporal-coded horns,
2
4 synchronizing the flash timing of the strobe, and silencing the horns of the
horn/strobe combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the Faraday series of horns, strobes, and
horn/strobes to provide a means of synchronizing the Temporal-coded horns, syn-
1, 3
chronizing the flash timing of the strobe, and silencing the horns of the
horn/strobe combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the Gentex
horn/strobes to provide a means of synchronizing the Temporal-coded horns, syn-
chronizing the flash timing of the strobe, and silencing the horns of the
horn/strobe combination over a two-wire circuit while leaving strobes active.
This mode is designed to work with the System Sensor
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
3 synchronizing the one-second flash timing of the strobe, and silencing the horns
of the horn/strobe combination over a two-wire circuit while leaving
strobes active.
This mode is designed to work with the CooperWheelock series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
1 synchronizing the one-second flash timing of the strobe, and silencing the horns
of the horn/strobe combination over a two-wire circuit while leaving
strobes active.
Descriptions
OFF
Output follows signal it receives from the corresponding input
2, 3 (i.e. FACP Sync module - maintains synchronization of
notification appliance circuit).
Enables Temporal Code 3 signal generation output.
1, 2
This mode will accept a steady or a pulsing input.
A steady output signal will be generated.
1, 2, 3
This mode will accept steady or pulsing input.
AL842LGK Board
(Output Dip Switches)
INPUT SELECT
STROBE SYNC
IN>OUT SYNC
® series of horns, strobes, and
® series of horns, strobes,
TEMPORAL
AL642ULADA
