Heat sink

Description
Heat sink (includes thermal cloth)
Before removing the heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the keyboard/top cover (see
5. Remove the battery (see
Remove the heat sink:
1. Remove the two Phillips PM2.0×2.0 screws (1) that secure the heat sink to the system board.
2. Lift the heat sink off the system board (2).
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and the system
board each time the heat sink is removed. Thermal material is used on the processor (1) and the heat sink
section (2) that services it.
36 Chapter 5 Removal and replacement procedures forAuthorized Service Provider parts
Keyboard/top cover on page
Battery on page 33).
Spare part number
792773-001
23).
