Left Side - HP Stream Notebook PC 13 Maintenance And Service Manual

Left side

Item
(9)
(10)
(11)
(12)
(13)
(14)
Component
Security cable slot
HDMI port
USB 3.0 port
Audio-out (headphone)/Audio-in (microphone)
jack
Memory card reader
Power light
Description
Attaches an optional security cable to the computer.
The security cable is designed to act as a deterrent, but it may not
prevent the computer from being mishandled or stolen.
Connects an optional video or audio device, such as a
highdefinition television, any compatible digital or audio
component, or a high-speed HDMI device.
Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner or USB hub.
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects an
optional headset microphone. This jack does not support optional
microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust the
volume before putting on headphones, earbuds, or a headset. For
additional safety information, refer to the Regulatory, Safety, and
Environmental Notices. To access this guide, from the Start
screen, type support, and then select the HP Support Assistant
app.
NOTE: When a device is connected to the jack, the computer
speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and audio-in
(microphone).
Reads optional memory cards that store, manage, share, or
access information.
To insert a card: Hold the card label-side up, with connectors
facing the slot, insert the card into the slot, and then push in on
the card until it is firmly seated.
To remove a card:
Press in on the card it until it pops out.
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a power saving
state. The computer shuts off power to the display and other
unneeded components.
●
Off: The computer is off or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.
Left side 5
