Specifications

Input Port
Output Ports
Output Video
ESD Protection
Power Supply
Dimensions (mm)
Weight (g)
Chassis Material
Silkscreen Color
Operating Temperature
Storage Temperature
Relative Humidity
Power Consumption
1 x VGA 15 pin D-sub
1 x RCA CVBS
NTSC/PAL
Human body model:
± 8kV (air-gap discharge)
± 6kV(contact discharge)
5V DC / 1A linear power adapter or 5V / 1.2A
switching power adapter (US/EU standards,
CE/FCC/UL certified)
64 (W) x 104 (D) x 26 (H)
120
Plastic
White
0°C ~ 40°C / 32°F ~ 104°F
-20°C ~ 60°C / -4°F ~ 140°F
20 ~90%RH (non-condensing)
3W
