- Page 1 Component & PC to Composite Video Scan Converter ID# 998 Operation Manual...
- Page 2 Introduction The Component & PC to Composite Video Scan Converter is designed to down scale Component and PC VGA signals to an analog Composite Video NTSC or PAL signal. Supporting SD/HD Component input from 480i/p to 1080i/p and PC resolutions VGA up to WUXGA@60hz, this scan converter scales down to either SD PAL or NTSC video for CV (yellow plug) connection to SDTV's.
- Page 3 Operating Functions Controls Top Panel 1. MENU Button (Hold): Press this button for 1 second to bring up the OSD which will display the input timing and output TV system information. While the OSD is still displaying press the button again for 5 seconds to switch to second tier OSD menu where changes can be made for e.g.
- Page 4 1.CV OUT: Connect with display TV or monitor with RCA cable for output image display. 2. 5v DC: Plug the 5V DC power supply into the unit and connect the adapter to AC wall outlet. OSD Menu (Input Press the Menu button once to Timing) operate the OSD to display the Source and Sink(monitor)
- Page 5 Diagram 2. Support Input Timing 640x480 60,72,75,85Hz PC Timing 720x400 70Hz 800x600 56,60,72,75,85Hz 1024x768 60,70,75,85Hz 1152x864 70,75,85Hz 1280x720 59,60Hz 1280x768 60rb,60Hz 1280x800 60rb,60Hz 1280x960 59,60Hz 1280x1024 59,60Hz 1366x768 60rb,60Hz 1440x900 60rb,60Hz 1600x1200 60Hz 1680x1050 60rb,60Hz...
- Page 6 1920x1080 59,60Hz PC Timing(cont) 1920x1200 60rb 480i 60Hz 480p 60Hz 576i 50Hz 576p 50Hz HD Timing 720p 50,60Hz 1080i 50,60Hz 180p 50,60Hz Note: When the input timing is not supported, the OSD will display “IN Not Support”. Not support interlace source signal conversion between 50/60Hz Not support 480i and 1080i@60 to PAL conversion Not support 576i and 1080i@50 to NTSC conversion...
- Page 7 Connection...
-
Page 8: Specifications
Specifications Input Port 1 x VGA 15 pin D-sub Output Ports 1 x RCA CVBS Output Video NTSC/PAL ESD Protection Human body model: ± 8kV (air-gap discharge) ± 6kV(contact discharge) Power Supply 5V DC / 1A linear power adapter or 5V / 1.2A switching power adapter (US/EU standards, CE/FCC/UL certified) Dimensions (mm)
