- Page 1 PC/HDTV to Video Scan Converter ID# 326 Operation Manual...
- Page 2 Introduction This unit is a high performance and multi-format video scan converter. It is designed to convert not only PC but also HDTV images to interlace NTSC/PAL and component output. It is ideal for use in video conferences, home theater, business presentations or viewing PC/HDTV images on TV. Features 1.
- Page 3 mode, illuminates in green when it is in “On” mode. 2. Power Button: Push the button to turn the power “On” or “Standby”. 3. Remote Control Sensor 4. Left Button: Push the button in order to adjust the picture leftward under position, pan or zoom mode.
- Page 4 Remote Control and Functions 1. Power: Power On/Off button. 2. Video setting adjustments: This is the setting adjustment for picture brightness, contrast, colour and sharpness. 3. V-Reset: Press the button in order to reset the picture adjustment to the factory default value. 4.
- Page 5 RS-232 Software Operation - PC/OS: Windows 98/ME/2000/XP. - Software installation: - Place the installation CD in the CD-Rom Drive. - Execute setup.exe on installation CD. - OS maybe requires updating some files. Please re-start the PC. After re- starting the PC, execute setup.exe again. - Click the taskbar menu (Start) - (Programs) - (Scan Converter) to execute software.
- Page 6 Connection and Installation - Connect the YCbCr, S-Video or Composite Video output port to your NTSC or PAL TV. - Connect the RS-232 connection cable to the RS-232 port. - Connect the HD Bypass (YPbPr) port to your PDP HDTV. - Connect the HD Input port to your DVHS or DVD player.
- Page 7 RS-232 Remote Control Protocol Pins Definition of Modem Cable...
