- Page 1 PC to TV Converter - Multi Vision ID # 521 Operation Manual...
- Page 2 Introduction PC to TV Converter - Multi Vision allows you to view computer images on a Standard, High Definition or Progressive Scan TV display, and features simultaneous display on TV and monitor. It is a Plug and Display device, and is powered from your PC's USB or PS/2 port. Most standard TV, HDTV, Progressive Scan TV's and most DVD, VCR and Projector devices are compatible with the PC to TV Converter - Multi Vision.
-
Page 3: Installation
1024 1152 Resolution 60,70,75 60,70 Vertical 60,66,72,75, 56,60,72, Frequency(Hz) 85,100,120 75,85,100 This converter fully supports APPLE iMac and iMAC DV computer display modes: Resolution 640x480 800x600 1024x768 Vertical frequency (Hz) Installation The following section shows the function of controlling the PC to TV Converter - Multi Vision Refer to Figure 1 for the Outline of... - Page 4 3. S-VIDEO OUT : Connects PC to TV Converter - Multi Vision your TV VCR or Video projector supporting the S-VIDEO input. 4. RGB OUT (SCART) : Connects PC to TV Converter - Multi to the RGB input of TV - VCR or Video projector. Vision 5.
-
Page 5: Remote Control
Remote Control POWER : Toggle between power on & off. VIDEO STANDARD: Press this button to select your video system. It supports NTSC, NTSC- EIAJ, PAL-M, PAL-N, PAL, PAL-COMBINATION-N. MENU : Press this button to cyclically activate the functions. These functions are Fine Tune, H-SIZE, V-SIZE Brightness, Contrast, Hue, Saturation, Flicker, OSD color &... - Page 6 Installation for IBM PC Users PC to TV Converter - Multi Vision is a “Plug and Display” video converter. The only thing required to get the image of computer on TV is to make the proper connection. Please read the following sections carefully for the installation of the hardware.
-
Page 7: Technical Tips
Please connect the Y Cable carefully as above connecting Please connect the Y.Cb.Cr to Y.Cb.Cr drawing otherwise it will cause you much inconvenience. cable as above connecting drawing. With the supplied video cable, connect to the converter’s VIDEO OUT to your TV or VCR video input. -
Page 8: Troubleshooting
Q: I connect with a NOTEBOOK PC, no output is displayed on TV. A: Check your computer hardware operating manual to enable the VGA port or “OUTPUT”.(Many Notebook computers have 3 settings, VGA external only, VGA internal only, and VGA internal & external simultaneously) Q: Can I use multiple televisions to view the same image from my computer? A: Yes, you may connect one television to the next using a composite video cable or an S- Video between the “VIDEO IN”... - Page 9 Converter - Ultimate XP 1.Toggle the video standard button to match your TV system. 2.Make sure the color (also called saturation for some TVs) setting is not minimum. No color 3. If your TV is multi-standard, set the standard to AUTO or the PC to TV Converter - Multi same as that output from the Vision...
