Top Panel
Specifications
1.
Timing button: Press this button once to show both the input and
output displays resolution and while the OSD is still on press it again to
select the output resolution from 720p to 1080p/1280 x 800/1366 x 768/1920
x1200(RB).
2. Power indicator: This LED will turn on when power is connected
TMDS Clock Frequency
Input port
Output port
HDMI Cable In*
HDMI Cable Out*
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Power Consumption
Operating Temperature
Storage Temperature
Relative Humidity
225MHz
1 x HDMI
1 x HDMI
1080p-8bits (6M)
1080p-8bits (6M)
5V/1A
DC
(US/EU
CE/FCC/UL certified)
114 (W) x 65 (D) x 26 (H)
78
Plastic
Black
2.7W
0°C~40°C / 32°F~104°F
-20°C~60°C / -4°F~140°F
20~90% RH (non-condensing)
standards,
