- Page 1 Coaxial/Optical to R/L Audio Converter - ID# 928 Operation Manual...
- Page 2 Introduction The Digital to Analog Audio Converter is an easy to use product that converts Coaxial or Optical audio signals into analog Stereo (R/L) audio. It can be easily switched between either Coaxial or Optical inputs. With its compact, elegant design and simple LED input status make it easier for users to connect up and use instantly.
-
Page 3: Right Panel
Operation Controls and Functions Front Panel 1. Coaxial/Optical Switch: Select which digital audio input is active and will be converted to analog stereo (R/L) audio. 2. DC 5V: Connect the 5V DC power supply to the unit and plug the adaptor into an AC wall outlet. -
Page 4: Specifications
Top Panel 1. Coaxial/Optical Input Status LED: The LED light will illuminate according to which input is currently selected. Specifications Input Ports 1×Coaxial, 1×Optical Input Format S/PDIF LPCM 2 CH, 24-bit Input Sampling Rate 32 kHz, 44.1 kHz, 48 k Hz, 88.2 kHz, 96 kHz, 176.4 kHz up to 192 Output Ports Analog Stereo (R/L) - Page 5 Connection...
