Specifications; Output Port - Converters.TV 975 Operation Manual

Specifications

Operation Data
Frequency Bandwidth
Input Port

OUTPUT PORT

SDI Video Supports
HDMI Cable Distance
SDI Cable Distance
ESD Protection
Power Supply
SDI Cable Distance
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Power Consumption
Operating Temperature
Storage Temperature
Relative Humidity
2.970 Gbps, 2.970/1.001 Gbps, 1.485Gbps,
1.485/1.001Gbps, and 270Mbps
225MHz/link (HDMI 1.3)
1 X HDMI, 1 X 3.5Ø PHONE JACK
1 X BNC (SD-SDI/HD-SDI/3G-SDI)
SD-SDI-480I, 576I,
HD-SDI-720P@50/60,1080I@50/60,
1080P@23.98/24/25/29.97/30
3G-SDI-1080P@50/60
10M
3G UP TO 100M
HD UP TO 200M
SD UP TO 300M
Human body model:
± 8kV (Air-gap discharge)
± 4kV (Contact discharge)
5V/2.6A DC (US/EU standards,
CE/FCC/UL certified)
3G UP TO 100M (BELDEN 1694A CABLE)
HD UP TO 200M (BELDEN 1694A CABLE)
SD UP TO 300M (BELDEN 1694A CABLE)
78 mm (W) × 124 mm (D) × 30 mm (H)
198
Aluminum
Silver
5 W
0ºC ~ 40ºC / 32ºF ~ 104ºF
-20ºC ~ 60ºC / -4ºF ~ 140ºF
20 ~ 90% RH (non-condensing)
