Converters.TV 998 Scan converter Operation Manual page 3

Operating Functions
and
Controls
Top Panel
Input Port
PC VGA
Component Y/Pb/Pr
Output Port
Composite Video
1. MENU Button (Hold): Press this button for 1 second to bring up the OSD
which will display the input timing and output TV system information.
While the OSD is still displaying press the button again for 5 seconds to
switch to second tier OSD menu where changes can be made for e.g.
output TV system from NTSC to PAL or from PAL to NTSC, Overscan,
Underscan, Aspect ratio etc. (Press the button to sequentially select the
desired parameter to be set.)
Power LED: This LED will illuminate in RED when the power supply
2.
is connected.
1. PC IN: Connect to source equipment such as PC, laptop or
digital camera with a D-sub 15pin output using a standard 15 pin D-
sub VGA cable.
1. Component In: Connect to source equipment such as
DVD/VCR/PVR player with a D-sub 15 pin to 3 RCA cable.
