5. Unpacking the Printer and Feeder

STEP 1
With two people lift the top (feeder) box off of the
bottom (printer) box.
STEP 3
Wing Nut
Remove the wing nut on the bottom of the feeder
before placing upright on any surface.
June 2011: Revision 002
STEP 2
Open the feeder box. Remove the feeder.
STEP 4
Back
of cart
Position the feeder at the back of the cart as shown.
8
