iSys iTerra Elite ll User Manual page 10

STEP 11
Remove the protective film.
STEP 13
Remove the letter tray shipping lock.
STEP 15
When the iTerra Elite II is fully assembled the printer
should look like the image above.
June 2011: Revision 002
STEP 12
Place the drums and toners back into the printer. Lock
all four toners into the four drums.
STEP 14
Keep the printer level while lowering it onto the feeder;
ensure you are aligning the printer with the pins
located on the top of the feeder.
10
