Media Set Up: Loading Paper into the Feeder, Option 2

STEP 1
Guide Door
Guide Tray Latches
Push the guide tray latches inward and pull the guide tray
forward about 12 inches.
STEP 3
Front loading paper path is pictured above.
June 2011: Revision 002
STEP 2
Push the guide tray latches inward and pull the guide
tray forward. Open the guide door, load door and
guide channels.
STEP 4
Insert paper in the front bottom loading slot until it
goes into the paper tray.
25
