7. Menu Functions

Feeder Operator Panel

1. Display

Printer Operator Panel

1.Ready LED
2. Display
3. Menu Scroll
Buttons
4. On Line
Button
5. Help Button
June 2011: Revision 002
1
Displays the feeder status and
any error messages
ON: Ready to receive data
BLINKING:
Processing data.
OFF: Offline
Displays the printer Status and any error
messages.
Enters the Menu mode. IN Menu mode,
forwards or reverses the menu item
displayed.
Press for 2 seconds or longer to jump from
top to bottom
Switches between ONLINE and OFFLINE
Scrolls the HELP screen
Forced printing on the paper currently
loaded when pressed with "WONG
PAPER" or "WRONG PAPER SIZE"
displayed.
Provides advice when an error such as
incorrect paper size occurs
2. Load Button
6. Attention LED ON: A warning occurs. Printing may be
possible (e.g low toner)
BLINKING: An error occurs. Printing not
possible (e.g toner empty)
OFF: Normal Condition
7. Back Button Returns to the previous higher level menu
8. Enter Button In the ONLINE or OFFLINE mode: enters
the Menu mode.
In the Menu mode: determines the setting
selected.
9. Cancel Button Deletes the data being printed or received
when pressed for two seconds or longer.
Deletes the data when pressed for two
seconds or longer with WRONG PAPER
SIZE, RUN OUT OF PAPER, TRAY 1 IS
OPEN, or TRAY 1 IS NOT FOUND is
displayed.
Exits the menu and goes ONLINE when
pressed in the Menu mode.
10.Power Save/
Pressing this button switches the machine
Wake up Button into sleep or wake- up mode. Refer to
"Power saving mode" page 12.
2
Press to complete loading
paper
