iSys iTerra Elite ll User Manual page 37

STEP 5
Remove the wrapping material and peel off the
adhesive tape from the underside of the cartridge.
STEP 7
Pressing gently down on the cartridge to ensure
that it is firmly seated, push the colored lever
towards the rear of the printer. This will lock the
cartridge into place and release toner into the
image drum unit.
Gently wipe the LED head surface with a clean, lint
free cloth.
June 2011: Revision 002
STEP 6
Insert the left end of the cartridge into the top of the
image drum unit first; pushing it against the spring on
the drum unit, then lower the right end of the cartridge
down onto the image drum unit.
STEP 8
Finally close the top cover and press down firmly at
both sides so that the cover latches closed.
37
