iTerra Elite II Rear View

This view shows the connection panel, the rear output stacker and the location of the optional duplex (two-sided printing)
unit.
1. ON/OFF switch
2. AC power socket
3. Duplex unit (when fitted)
4. Rear, face up stacker
* The Network Interface may have a protective "plug" which must be removed before connection can be made. This view
shows the connection panel, the rear output stacker and the location of the optional duplex (two-sided printing) unit.
June 2011: Revision 002
5. USB interface
6. ACC interface (host USB)
7. Network interface*
8. Parallel interface
12
